IS680 is considered when a commercial RF board needs lower loss than ordinary FR-4 but the cost and processing complexity of a conventional PTFE construction are difficult to justify. The family is offered in multiple dielectric-constant grades, so the first...
Isola 185HR belongs on a manufacturing page about reliability, not on an RF-material page. It is specified when a multilayer PCB must survive lead-free assembly, repeated thermal exposure, demanding plated holes, humid-bias service or a long product life. The useful...
TMM13i is used when a microwave circuit must become very small and the designer needs a nearly isotropic, very high-Dk thermoset substrate. The material can compress resonators, filters, patch antennas and matching networks, but the electrical benefit shifts attention...
RT/duroid 6006 is selected when circuit area is expensive. Its high dielectric constant can shorten filters, resonators, patch antennas and amplifier matching networks, but the smaller geometry brings tighter tolerance and stronger temperature sensitivity. The useful...
TMM4 is most useful when a microwave circuit must become smaller without moving immediately to an extreme high-Dk substrate. That makes it a practical material for compact filters, resonators, couplers, matching networks and housed RF modules where center frequency...
RT/duroid 5870 is chosen when the RF path needs low loss, low dielectric constant and broad-frequency stability, but the manufacturing route is less forgiving than a standard thermoset laminate. The same PTFE-rich structure that supports wideband antennas and long...
TMM3 is selected when an RF circuit must behave as part of a mechanical module. The board may include machined cavities, mounting holes, plated edges, wire-bond pads, clamps or a metal housing. In that environment, low loss is only one requirement; rigidity,...
A 77 GHz radar board is purchased as a working sensor platform, not as a sheet of RO3003. The customer ultimately cares about antenna alignment, feed-network phase, launch return loss, assembly consistency and radar performance over temperature. That is why a radar...
RO4835T is useful when the RF layer must move inside the multilayer stack without consuming the thickness of a conventional microwave core. The buying decision is therefore tied to board architecture: dense radio modules, phased-array feed networks, compact...
RO4003C is often the point where an RF project stops behaving like an ordinary FR-4 board. The change is not driven by the material name alone. It normally happens because insertion loss, phase consistency, filter response, antenna feed stability or production...
