Highleap ElectronicsによるLED街路灯用PCBの製造および組立

Highleap Electronics is a PCB fabrication and assembly factory that manufactures LED street-light boards to your specification. We are not a luminaire brand selling finished fixtures — we are your contract manufacturer: you bring the design (or a specification for us to engineer to), and we fabricate the bare boards and assemble them into the light engines and driver boards your product needs. We build to your print or design to your requirements, under OEM and white-label terms, on our 金属コアPCB lines. ISO 9001, IPC Class 2/3, MOQ 1 unit, quote within 24 hours.

This page explains what we manufacture for roadway luminaires, the engineering decisions that govern a reliable street-light board, and how to order. To start, send us your Gerber files and BOM 当日中に見積もりを出します。

1. Why Lighting Brands Choose Highleap as Their Street Light PCB Manufacturer

A street-light board is not a generic PCB. It dissipates 30–250 W in a sealed, pole-mounted housing, must hold output for 50,000–100,000 hours, and sits at the end of a long cable run that channels surges into the driver. A general-purpose fab that treats it like ordinary 2-layer FR-4 produces boards that fade and fail in the field. As a specialist contract manufacturer, we build to those stresses — to whatever specification and workmanship class you require.

• 仕様に基づいた製造 — we fabricate and assemble to your design and standards; supply finished Gerbers, or have us engineer the board to your performance requirements.
• 金属コア専門化 — アルミニウムと 銅芯 light engines fabricated and thermally validated in-house, not subcontracted.
• Full board set, one supplier —軽エンジン、 ドライバーボード, surge protection, and control board manufactured together, so you avoid coordinating multiple vendors.
• 最小注文数量 1 個 — prototypes built to the same standard as production, with no prototype surcharge.
• ISO 9001 and IPC Class 2/3 — workmanship class selectable per order; OEM/white-label with NDA.
• 24時間の見積もり with a free Design-for-Manufacturability (DFM) review on every order; ships to 40+ countries.

2. Fabricating the Street Light Light Engine — Aluminum MCPCB

The light engine is the thermal heart of the luminaire. Because the fixture is sealed, the board is the primary heat path from the LED junction to the heat sink, which is why street-light engines are fabricated on an aluminum metal-core substrate rather than FR-4. We manufacture this board to your stackup, or recommend one to meet a thermal target you specify.

The thermal stack is a series of resistances from junction to ambient: junction-to-case inside the LED, case-to-board through the solder joint, board-through the dielectric and metal core, and board-to-heat-sink across the mounting interface. The dielectric is usually the dominant board-level term, so its conductivity and thickness are the first parameters we confirm with you. A 100 µm dielectric at 2 W/m·K behaves very differently from one at 5 W/m·K — on a 150 W cobra-head that can shift junction temperature 15–20 °C, changing the lumen-maintenance curve. We model this budget for your wattage before fabrication.

Fabrication parameters we manufacture to

• 基板 — aluminum core 1.0–3.0 mm (5052 standard); copper core for high-flux high-mast heads where aluminum cannot shed heat fast enough.
• 誘電 — 1.0–3.0 W/m·K standard, 5–8 W/m·K for dense arrays; the dielectric sets junction-to-case resistance.
• 銅の重量 — 1–2 oz standard, 3–4 oz for high single-string currents and lateral spreading.
• 表面仕上げ — OSP or ENIG; ENIG for fine-pitch LED pads and shelf life.
• 戦士の表情 — high-reflectance white to recover stray light.

Background on substrate selection is in our アルミニウムLED PCB reference and MCPCB thermal-conductivity guide.

3. LED Assembly and Driver Board Manufacturing

A working luminaire needs the diodes placed and tested and the driver that powers them. We assemble both to your BOM, and manufacture the surge and control boards roadway fixtures require.

LED placement and binning

• SMDアセンブリ — 2835/3030/5050 emitters placed per your layout; see SMD LED PCB assembly.
• COB light engines — single dense emitters for compact beams; see COB LED PCB solutions.
• Binning control — we source and sort to the CCT/flux bin you specify (or source to it ourselves), then lit-test every board for fixture-to-fixture consistency.

Driver and protection board build

• Constant-current driver boards — assembled to your design or engineered to your electrical spec; see LED driver PCB and the power-factor-correction 舞台。
• サージ保護 — 10 kV / 10 kA SPD integrated on the driver or as a separate module per your requirement.
• 調光/制御 — 0–10 V, DALI, and NEMA/Zhaga socket interfaces built per your control specification.

For high-mast drivers we fabricate heavy-copper power stages where the current demands it.

4. Roadway Luminaire Types We Manufacture For

“Street light” spans a family of fixtures, each shaping board size, optic, and mounting. The LED layout on the board is the foundation of the photometric distribution, working with your secondary optic to land light on the road and limit spill. We manufacture boards for the full range:

• Cobra-head / arm-mount luminaires — 30–150 W, single rectangular MCPCB or tiled modules with a driver tray.
• High-mast area lighting — dense, high-flux arrays for interchanges and ports.
• Highway luminaires — manufactured to IPC Class 3 with surge-hardened drivers.
• Residential and pathway lights — lower wattage, often paired with a photocell board.
• Smart / connected street lights — NEMA/Zhaga, 0–10 V, DALI, or wireless control boards.
• Retrofit modules — boards manufactured to match your legacy HPS or metal-halide gear plate exactly.

We arrange the emitter grid to your target optical distribution (Type II–V) and hold tight placement tolerance so your lens array registers correctly and the fixture meets the photometric and dark-sky targets you are designing to.

5. Thermal, Surge and Environmental Engineering to Your Standard

Street-light reliability is decided by three factors, all landing on the board. We engineer each into the manufactured board against the standard you specify, rather than leaving it to the housing.

• 熱経路 — minimized junction-to-case resistance through dielectric, copper, and a flat, burr-free board back that mates cleanly to your heat sink; this governs LEDの熱性能 and slows ルーメン減価償却.
• サージ耐性 — 10 kV / 10 kA protection built to survive lightning-induced transients on exposed poles.
• 湿気と腐食 - コンフォーマルコーティング on the assembled board, with the moisture-resistant build practices of our 防水PCB work for coastal sites.

For municipal and highway programs we manufacture to IPC Class 3 and screen with バーンインテスト to remove infant-mortality failures before your fixtures reach the field. The lumen-maintenance rating (L70/L80/L90) you design around is fundamentally a thermal outcome — a cool junction is what lets the fixture you sell hold its rated output.

6. Street Light PCB Capabilities & Specifications

Our fabrication and assembly capabilities for roadway luminaire boards, from standard production to advanced high-mast builds — all manufactured to your specification:

7. 注文方法 ― ファイル、最小注文数量（MOQ）、納期

Ordering manufacturing from us is straightforward whether you have production files or only a specification. Every quote includes a free DFM review, and we build to your design and standards.

何を送るか

• 製造のみ — Gerber RS-274X, Excellon drill file, board outline, and fab notes (substrate, dielectric, copper, finish, mask).
• アセンブリ（PCBA） — the above plus a BOM with manufacturer part numbers and a Pick-and-Place file; you supply components or we source to your BOM.
• Turnkey light engine — the above plus heat-sink/housing data, optic and driver spec, and any branding; no finished files yet? Send your specification and our engineering team will design the board to it.

最小注文数量、リードタイム、規格

• MOQ 1ユニット試作品追加料金なし。数量割引は10/50/100/500/1,000以上で適用されます。
• Fabrication 5–7 business days (24–48 h express); PCBA 7–12 days; turnkey modules 12–18 days.
• ISO 9001, IPC Class 2/3, AOI and lit test on every board; OEM/white-label with NDA; we retain your files for repeat orders.

開始するには、 ガーバーファイルと部品表をメールで送信してください。 お見積もりは1営業日以内にお送りいたします。

8. LED Street Light PCB FAQs

Does Highleap sell finished street lights, or manufacture the boards?

We are a PCB fabrication and assembly factory, not a luminaire brand. We manufacture the boards — the aluminum light engine and the driver board — to your specification and standards, as bare PCBs, populated PCBAs, or complete wired light engines ready for your housing. You design and sell the finished fixture under your own brand; we are your contract manufacturer and OEM/white-label partner.

Can you design the board if I only have a specification, not Gerber files?

Yes. You can supply finished Gerbers for us to build to print, or send a specification — target wattage, optical distribution, driver and control requirements, environment — and our engineering team will design the light engine and driver to it, then fabricate and assemble. Either way you own the resulting design, and we keep your files on file for repeat orders.

Why do LED street lights require an aluminum PCB instead of FR-4?

Roadway LEDs dissipate concentrated heat in a sealed housing and must run for 50,000–100,000 hours with minimal lumen loss. An aluminum metal-core board conducts heat away from the junction far better than FR-4, keeping junction temperature low. Because LED output and lifetime both fall as junction temperature rises, this controls lumen maintenance, color stability, and service life — so we fabricate quality street-light engines on aluminum MCPCB.

Can you build to a specific IPC class and supply documentation for tenders?

Yes. We manufacture to IPC Class 2 or Class 3 workmanship, selectable per order, with Class 3 for municipal and highway programs. We provide material traceability, build records, and test documentation on request, and screen with burn-in testing where reliability is critical — supporting the compliance evidence your tender or customer requires.

Do you source components or do I supply them?

Either. You can consign your own components, or we source the full BOM through our verified distributor network, including matching the LED bin and color temperature you specify. Every assembled board is lit and verified before shipment, with binning documented for color-critical roadway programs.
