Highleap Electronic’s Approach to PCB Quality Assurance

X-ray inspection

Key Factors in PCB Quality Control

PCBs are essential components in electronic devices, responsible for their functionality and performance. Ensuring the production of high-quality PCBs is crucial for the reliability and efficiency of these devices. This article discusses the key factors that contribute to good PCB quality control.

1.Design for Manufacturing (DFM)

Design for Manufacturing (DFM) is a process used in the design stage of product development to optimize the product’s design for efficient manufacturing, assembly, and quality. The goal of DFM is to reduce production costs, improve product quality, and shorten the time to market.

DFM considers various factors such as material selection, component placement, tolerances, and manufacturing processes to ensure that the product can be manufactured easily and cost-effectively. By designing with manufacturing in mind, designers can minimize potential issues that may arise during production, assembly, or testing.

Key principles of DFM include:

  • Simplify the design: Reduce the number of parts and complexity of the product to streamline manufacturing and assembly processes.
  • Standardize components: Use standardized, readily available components to simplify sourcing and reduce costs.
  • Minimize manufacturing steps: Design parts that can be manufactured using the fewest number of steps, reducing production time and costs.
  • Design for assembly (DFA): Ensure that components can be easily assembled into the final product, minimizing assembly time and complexity.
  • Consider manufacturing constraints: Take into account the capabilities and limitations of the manufacturing processes that will be used to produce the product.
  • Use appropriate materials: Select materials that are suitable for the intended application and can be easily sourced and processed.

DFM is a critical aspect of product development that can have a significant impact on the efficiency and cost-effectiveness of manufacturing processes. By incorporating DFM principles early in the design process, companies can optimize their products for successful production and market success.

2.PCB Manufacturability

PCB manufacturability is crucial for ensuring the performance and reliability of printed circuit boards. Proper PCB manufacturing processes are essential for producing high-quality PCBs that meet the required specifications and performance standards. Adhering to all technological requirements for PCB manufacturability is key to ensuring the success of the PCB manufacturing process. This includes following industry standards and guidelines, using the right materials and components, and employing the correct manufacturing techniques. By focusing on PCB manufacturability, manufacturers can produce PCBs that meet or exceed customer expectations for performance and reliability.

3.Testability and Normalization

Testability and normalization are critical aspects of ensuring the quality and reliability of PCBs. PCBs must meet national and industrial standards to ensure they perform as expected and meet safety requirements. This includes passing standard tests such as surface finish and electrical tests.

Surface finish tests are conducted to ensure that the surface of the PCB is properly finished, which is essential for ensuring good solderability and preventing oxidation. Electrical tests, on the other hand, are performed to verify that the PCB meets the required electrical specifications and can function correctly within the intended application.

By adhering to these standards and conducting thorough testing, manufacturers can ensure that PCBs are of high quality and meet the necessary performance standards. This is essential for the reliability and performance of electronic devices that rely on PCBs for their operation.

4.PCB Quality Control for Component Procurement

  • BOM validation ensures that only components in the PCB design are acquired.
  • Verify Manufacturer Part Numbers (MPNs) and Component Reference Designators to avoid buying incorrect components.
  • Check the status of component manufacturers to ensure future production availability.
  • Ensure MPN footprint match for correct component placement.
  • Verify kit accuracy to avoid delays and extra costs.
  • Perform documentation review, visual inspection, solderability testing, and component tolerance check to confirm correct components.

5.Quality Control in PCB Production:

  • IPC certification ensures manufacturers adhere to standards and criteria.
  • Inspection and validation before production ensure PCBs match customer requirements.
  • Use high-quality standard components for PCB assembly.
  • Implement well-documented process controls to regulate manufacturing quality.
  • Conduct assembly checks using manual and automated inspection equipment.
  • Thoroughly inspect completed PCBs to ensure quality.
  • Maintain a well-organized and well-maintained assembly line for quality finished products.

6.PCB Assembly Quality Control Testing:

  • Conduct visual inspection, automated optical inspection (AOI), X-ray inspection, and sawing tests during assembly.
  • Use resistivity of solvent extract (ROSE) testing to determine PCB cleanliness.
  • Perform electrical testing and metalized inspection for double-sided and multi-layer PCBs.

Verifying the Quality of PCBs: Highleap Electronic’s Approach

At Highleap Electronic, we understand the importance of PCB quality assurance and have developed methods to distinguish between high-quality and poorly designed boards. We will discuss seven ways to judge the quality of a PCB.

  • PCB Traces: Start by examining the PCB traces. They should have a solder mask layer to prevent shorts or oxidation. Green solder masks are preferred as they allow for better visibility of traces. Ensure that all traces are straight, as bends can reduce efficiency, especially in high-power applications.
  • Decoupling Capacitors: Check the placement of decoupling capacitors, which help cancel out high-frequency interference. Each chip with multiple VDD pins should have at least one decoupling capacitor placed close to its pins. Improper placement can lead to a drop in chip and PCB efficiency.
  • Length of PCB Traces: In designs where the timing relationship between multiple signals is crucial, ensure that all PCB traces are of equal length. This is important for signals like high-speed clock signals or data lines between RAM and a microprocessor.
  • Antenna Feedlines: For PCBs with transmitters, receivers, or transceivers, ensure that the feedline between the RF chip’s pin and the antenna is matched in terms of impedance. Impedance matching is essential for maximum power transfer and optimal performance.
  • Component Placement: Pay attention to the placement of components other than decoupling capacitors. Inductors, for example, should not be placed too close to each other or to metal objects, as this can lead to unwanted coupling or induced currents.
  • Trace Width & Routing: Traces accommodating high currents should be sized correctly, following standard trace width guidelines. Traces carrying small analogue signals can run parallel to those carrying digital signals, but caution must be taken to avoid interference.
  • Grounds & Ground Planes: Use a Multi-layer board for moderately complex PCBs, with 2 layers acting as supply and ground planes. If the PCB design includes a mix of analogue and digital sections, consider splitting the ground plane and joining it at the negative terminal of the power supply to prevent ground current spikes.

In addition to these methods, effective PCB quality control involves managing and monitoring PCB design, manufacturing, and inspection processes. Ensuring the correctness of design files, manufacturability, standardization, and testability are crucial aspects of PCB quality control. By following these guidelines, you can ensure that the PCBs you use are of the highest quality, whether you design them yourself or collaborate with a PCB manufacturer.

X-ray inspection

Highleap Electronic’s Approach to PCB Quality Assurance

 At Highleap Electronic, we prioritize quality assurance testing to ensure our PCBs meet the rigorous standards of modern electronics manufacturing.

Quality Assurance Testing Methods

  1. In Circuit Testing (ICT) ICT is a standard method for testing PCBs, focusing on open and short circuits, component values, and IC operation. Highleap uses advanced ICT equipment to ensure the functionality and integrity of our PCBs.
  2. Automated Optical Inspection (AOI) Our AOI process utilizes state-of-the-art 3D and 2D cameras to inspect PCBs for defects. This allows us to quickly and accurately identify issues such as loose solder connections, ensuring the quality of our products.
  3. Flying Probe Test Highleap employs the flying probe test to check for various issues, including open circuits, short circuits, capacitance, resistance, inductance, and diode problems. This non-powered test is efficient and effective, providing valuable insights into PCB quality.
  4. X-Ray Inspection (AXI) AXI is a crucial tool in our quality assurance arsenal, allowing us to inspect solder connections, barrels, and internal traces in 2D and 3D formats. This enables us to detect defects that may not be visible to the naked eye, ensuring the reliability of our PCBs.
  5. Functional Test Functional testing is a key step in our quality assurance process, ensuring that our PCBs work as intended. Highleap follows standard specifications such as UL and MSHA to guarantee the performance and safety of our products.
  6. Burn-In Test For applications requiring high reliability, we conduct burn-in tests to detect failures in advance and determine load capacity. While intensive, this test is essential for ensuring the long-term performance of our PCBs.

At Highleap Electronic, we are committed to delivering high-quality PCBs that meet the demanding requirements of modern electronics manufacturing. Our rigorous quality assurance testing methods ensure that our products meet the highest standards of performance and reliability, providing our customers with the confidence they need in their electronic products. Contact us today to learn more about our PCB quality assurance measures and how we can meet your specific needs.

General operations of Highleap PCB Quality Control

Ensuring the quality of printed circuit boards (PCBs) is paramount to meeting customer expectations and industry standards. At Highleap, we prioritize quality by implementing rigorous quality control measures and utilizing advanced inspection and testing equipment.

  1. ISO and QS9000 Certification: We adhere to the ISO9001 and QS9000 quality management systems, ensuring that our processes meet international standards for quality assurance.
  2. DRC Check: We perform a Design Rules Check (DRC) to verify that the layout of the PCB meets all design constraints and rules, ensuring the integrity of component placement and trace routing.
  3. 100% Electrical Testing: For prototype orders, we use Flying-Probe E-Test to check for short circuits, open circuits, and net consistency with your design. For production orders, we use testing fixtures to ensure the same quality standards.
  4. AOI (Automated Optical Inspection): We use AOI to inspect the inner layers of multi-layer PCBs, detecting features such as line width violations, spacing violations, excess copper, and more, with high reliability and repeatability.
  5. Quality Control System: Our quality control system is ISO 9001:2008 certified, ensuring that all processes are documented, monitored, and regularly audited for conformance and effectiveness. We also have procedures in place for dealing with non-conformances and improving our system.
  6. UL Certification: We comply with UL safety certification 94V-0, ensuring that our PCBs meet strict flame rating requirements. Our UL number is E472163, and all our products satisfy UL requirements.
  7. RoHS Compliance: Our PCBs meet the requirements of the Restriction of Hazardous Substances Directive (RoHS), ensuring that they do not contain hazardous materials such as lead, mercury, or cadmium.

Our commitment to quality extends throughout the entire production process, from design to manufacturing to inspection. By adhering to international standards and utilizing advanced technologies, we guarantee the quality and reliability of our printed circuit boards.

Conclusion

In the realm of online PCB self-ordering, the absence of dedicated engineers overseeing your project can be a critical oversight. Automated processes, driven by software scripts, often fall short in detecting nuanced design flaws, potentially compromising PCB quality and project timelines. At Highleap, we take a different approach. Our personalized, one-on-one engineering service ensures that your PCB project receives the attention it deserves. With an experienced team of CAM engineers, we guarantee not just quality, but a meticulous eye for detail, ensuring your PCB project is executed flawlessly. Trust Highleap for your PCB needs, and rest assured that your project is in expert hands.
